TBOX-4T31

TAICENN TBOX-4T31 Modular Box PC is Powered by the Intel 11th Gen. Tiger Lake UP3 Core i7-1165G7 Quad-core processor, which have super high cost-performance for industrial automation applications. Its advanced industrial design includes a DC terminal with a wide DC 9~36V range power input. The TBOX-4T31 industrial Box PC is designed with rich I/O interfaces that includes 2x USB 3.1 & 2x USB 3.0 ports, 1x USB-C (USB3.1 & DP1.4a), 2x DB9 RS232/RS485/RS422(BIOS configured), 1x SW Remote Switch, 2x HDMI, 2x GbE LAN ports, Audio port, optional 1x GPIO (8-ch). This fanless PC provides 3 high speed expansion slots (1* M.2 3042/3052 B-Key, 1* M.2 2230 E-Key, 1* Mini-PCIe),can optional support 3G/4G, 5G, Wi-Fi6, Wi-Fi/BT wireless functions. Also, TPC-DCT/DRT T series provides more powerful expansion possibilities, and offer flexible and fast expansions for industrial field applications to improve product performance. The TBOX-4T31 also support TPM2.0, can be compatible with Windows10, Windows11, Linux Operating system and embedded Operating system.
